Smart Wall
Thermal shop front screen and door system
Smart Wall is a thermal shop front screen and door system suitable for all types of ground floor treatment where enhanced thermal performance is required. The system is ideal for use in schools, colleges and other educational buildings.
Smart Wall has been successfully tested to PAS 24:2012, LPS 1175 level 2 and BS EN 1627 Level 3 for enhanced security performance making the door one of the best performing fully thermally broken screen and entrance doors available in the UK. Screen work is either beaded or pocket glazed. Smart Wall complies with the latest requirements of Document L for thermal transmittance.
| Smart Wall | |
|---|---|
| Application | Commercial |
| Finish | Single / dual colour, marine quality polyester powder coated |
| Profile | Flat |
| U Value | 1.8 w/m²k Doors / 1.4 w/m²k Screens |
| Security | Ultion (diamond accredited) Cylinder as standard - Hook lock |
| Profile depth | 100mm |
| Profile width | 53mm |
| Single Door Max Width (mm) | 1100mm (per sash) |
| Single Door Max Height (mm) | 2500mm (per sash) |
| Single Door Max Weight (kg) | 80kg |
| Add ons | 53mm |
| Bead | External |
| Cills | 85mm, 150mm, 190mm, 225mm, 300mm |
| Glazing | DG 28mm |
