Our sliding doors provide the maximum light and afford the most unobstructed views of any system when closed and with our wide range of systems and options, you can select and tailor a door system to exactly meet your own specific requirements.

With a choice of frame sizes, sliding formats wethertwo, three or four pane systems, together with a choice of high-quality hardware and a wide range of colour options, the slim lines of these elegant doors make them the perfect solution for any home.

visoglide patio doors

*Standard sash unless specified.

Visoglide Plus
Application Domestic / Commercial
Finish  Single / dual colour, marine quality polyester powder coated
Profile Flat only
Security  Ultion (diamond accredited) Cylinder as standard - multi-point locking
Frame depth  116mm DT  /  182.5mm TT
Max sash weight  250kg
U Value  1.4 - 1.8 w/m²k
Max o/a height (per sash)  2500mm
Max o/a width (per sash)  Within height/weight limitations there is no maximum width
Air Tested Class 3, 600Pa
Water Tested Class 7a, 300Pa
Wind Tested Class AE, 2400Pa
BSA Awards  KM 530838 PAS 24:2012
Glazing  DG 28mm / TG 36mm
Track Double  / Triple Track
Interlock Width Slider Std 83mm  / Lift & Slide 99mm  / Slim 35mm
Add ons 42mm
Bead Internal Only
Cills 150mm, 190mm, 225mm, 300mm

CONFIGURATIONS

visoglide patio doors
