Shopline
A modular screening solution
Shopline is a modular screening solution, combining the benefits of off-site manufacture with on-site assembly. Screen modules are constructed offsite from square cut profiles joined using self tapping screws. These modules can then be rapidly assembled onsite, intuitively clipping together the mullions to form one continuous screen.
This rapid assembly method offers an economical solution for low rise screening with slim sightlines of 50mm. Designed for the UK climate, all fixings on the screen are manufactured from corrosion resistant material to provide protection from both atmospheric and electrolytic degradation. The system offers drainage trays, ensuring the screens performance in all weathers.
Shopline | |
---|---|
Application | Commercial |
Finish | Single colour |
Profile | Flat |
Security | Ultion (diamond accredited) Cylinder as standard - Hook lock |
Profile depth | 100mm |
Profile width | 50mm |
Single Door Max Width (mm) | 1100mm (per sash) |
Single Door Max Height (mm) | 2500mm (per sash) |
Single Door Max Weight (kg) | 110kg |
Add ons | 50mm |
Bead | External |
Cills | 85mm, 150mm, 190mm, 225mm, 300mm |
Glazing | DG 24mm |
