EcoFutural Window
A choice of either tilt & turn or fixed windows.
Our outstanding, high-performance window range is brought together under the EcoFutural name, offering a wide choice of options for the ultimate in thermal performance and weather protection. The range offers a choice of either tilt & turn or fixed windows.
The EcoFutural system features our proven chambered polyamide thermal break that creates a barrier between the cold air outside and the warm air inside. This technology significantly reduces thermal transmittance and enhances the overall U-values of every EcoFutural window.
| Alitherm 300 Windows | |
|---|---|
| Application | Commercial / Domestic |
| Finish | Single / dual colour, marine quality polyester powder coated |
| Profile Sash | Square |
| Security | Multi-point locking, Inline locking handle as standard |
| Frame depth | 65mm |
| Max weight | 90kg |
| U Value | 1.1 -1.4 w/m²k |
| SH Max o/a width | 1700mm |
| SH Max o/a height | 2500mm |
| WER | A - C |
| Air Tested | Class 3, 600Pa |
| Water Tested | Class 7a, 300Pa |
| Wind Tested | Class AE, 2400Pa |
| British Standards | KM 81580 / PAS 24:2016 / KM81543 / BS6375 |
| Add ons | 20mm, 42mm |
| Bead | Internal |
| Cills | 85mm, 150mm, 190mm, 225mm, 300mm |
| Glazing | DG 28mm |
| Astragal Bar | 25mm / 41mm flat bar |
